Low voltage power capacitor Type Rg-2 (Indoor use)

Applied Standard
The capacitors are designed manufactured and tested to meet the requirement of IEC Publication No.60831 , JIS C 4901

Operating Consolidations

Installation: Indoor
Ambient temperature: -25℃ to +45℃ (class C)
Altitude: not exceeding 2000 meters above sea level

Type and Ratings

Type: RG-2
Rated Voltage: see the tables showed on catalog page 3,4,5
Rated output in kvar: see the tables showed on catalog page 3,4,5
Rated frequency: 50Hz (60Hz is also available upon request).
Phase and connection: three (3) phase and delta. (Single phase unit is also available upon request)

Design and Construction

Element: Metallized polypropylene film and self-healing type.
Impregnation: Less-flammable liquid insulation, non-PCB oil, non-toxic and environmentally compatible.
Designation: suit for mounting in vertical position with bushing on top.
Container: Galvanized steel sheet.
Color: Non-corrosive poly-urethane resin enamel Munsell notation 5Y7/1

*** The above information may possibly differ from the latest version. Please feel free to contact us for further support.
