MEC-HV

Features

Maintenance-free (lifetime expectancy of 175200 hours 20FIT)
Safety design (Self-healing, open failure mode)
No polar
Dry-type capacitor (no electrolysis solution and oil)
Easy mounting by stat bolt
Withstand high ripple current(current capacity per capacitance is more than 10 times electrolytic capacitor)
Small size/High energy density (Energy density is 50% up to our conventional product design)

General Specifications

Reference standard: IEC 6170, JEM 1419
Capacitance Range: 370uF to 1600uF
Capacitance Tolerance: ±5%
Rated Voltage: 900VDC, 1100VDC, 1200VDC
Max temperature: ≤85℃ (hotspot)
Ambient Temperature Range: -20℃ to 50℃
Dissipation Factor: ≤ 2 x10-4
Self-Inductance: 45nH (typical value)
Test Voltage (T-T): Rated voltage x 1.5VDC
Test Voltage (T-C): Rated voltage 900VDC:3000VAC, 1100VDC:3200VAC, 1200VDC:3400VAC
Life time expectancy: 20 years 175,200 hours at R.V and 70℃ (hotspot)
Failure Rate: 20 Fit at R.V and 70℃ (hotspot)
Resin: UL94 V-0
